EPTE Therapeutic percutaneous electrolysis: Therapeutic percutaneous electrolysis (EPTE) is an invasive physiotherapy technique that consists of the application of micro-currents through an acupuncture needle, which allows perfect access to the tendon. 100% Spanish product.
Technical specifications:
- Dimensions: 220x140x46mm.
- Container: ABS box with high impact resistance.
- Weight: 350g (without batteries).
- Power supply: 3 non-rechargeable AA 1.5V alkaline batteries.
- Consumption: 35mA.
- Autonomy: 3100 treatments (500μA / 10KΩ for 80Sg).
- Equipment classification: class IIa, according to rule 9 of directive 93/42/EEC on medical devices.
- Current waveform: continuous *** .
- Maximum output voltage: 48V.
- Minimum output current: 50μA.
- Maximum output current: 2500μA.
- Minimum current resolution: 10μA.
- Minimum time resolution: 5μSg.
- Maximum treatment time: unlimited.
- Screen:
- Dimensions: 80x36mm.
- Type: Reflective Alphanumeric LCD Display
- Resolution: 16 characters x 2 lines.
- Maximum vertical viewing angle: 40º.
- Maximum horizontal viewing angle: 30º.
- Operating temperature: 0ºC to 40ºC.
- Storage and transport temperature: from -20ºC to 60ºC.
- Humidity: 5% to 95% relative humidity, non-condensing.
- Electromagnetic compatibility test standards: EN 60601-1-2 (2007). Corrigendum 2010.
- Electrical safety test standards: EN 60601-1: 2006. Corrigendum 2010 IEC 60601-2-10: 2012.
*** The treatment is composed of two current modes. Initially, the current rises until it reaches the nominal value of the treatment, at which point the stationary or continuous mode begins.
Compatible accessories (not included):
- Ref. 077-PDV01 : Application pedal-button for echoguided EPTE.
